No mundo da tecnologia de exibição externa de alto impacto, desempenho, estabilidade, e confiabilidade a longo prazo são fundamentais. O LEDcheer FP Series stands as a premier outdoor LED display solution designed to withstand demanding environments while delivering vibrant and crystal-clear visuals. Ranging from P4.44 to P10 pixel pitches, a Série FP é ideal para estádios, outdoors comerciais, sinalização de trânsito, e sistemas de anúncio público.

Built with SMD1921/SMD2727 LED configurations, a Série FP combina precisão de engenharia e excelência visual, oferecendo brilho poderoso, construção à prova de intempéries, e vida útil operacional excepcional.

🛠️ Built for Safety and Stability

Safety is one of the core values behind the FP Series. O sistema de gabinete é projetado tendo em mente a integridade estrutural e as condições externas. The die-cast aluminum cabinet measures 960mm x 960mm x 77mm, fornecendo robustez e dissipação de calor consistente. It weighs only 25kg, garantindo transporte e manuseio mais fáceis sem comprometer a resistência.

The FP Series also supports dual-voltage power distribution for improved efficiency and safety across different regions and installation requirements. Its operating voltage range of AC100–240V (50/60hertz) garante adaptabilidade em vários mercados internacionais.

🌦️ Certified Outdoor-Grade Protection

With IP65 front and back waterproof ratings, os módulos de exibição estão totalmente protegidos contra poeira, chuva, e umidade. Operating temperature ranges from -20°C to +50°C, e o sistema tolera níveis de umidade de até 95% RH, tornando-o adequado para ambientes externos extremos.

O produto foi projetado para 24/7 uso, ostentando uma vida profissional de mais de 100,000 horas.

💡 Bright and Dynamic Visuals

When it comes to performance, a série LEDcheer FP impressiona em todos os aspectos:

• Brightness levels exceed 6000–6500 nits, ensuring visibility even in direct sunlight.
• Taxa de atualização de ≥3840Hz provides smooth, flicker-free visuals—ideal for video and dynamic content.
• Wide 140° viewing angle ensures consistency across large audiences.
• 14-bit grayscale e 16.7 million display colors contribute to sharp image transitions and lifelike color rendering.
• Brightness adjustment de 0 para 100 levels enables optimal calibration in different environments.

📏 Pixel Pitch Options

The FP Series is available in five pixel pitch variants:

This range allows clients to select the ideal model based on viewing distance, resolution needs, and budget constraints.

🔧 Smart Heat Dissipation & Power Management

The FP Series features a dedicated heat dissipation structure, enabling effective airflow and thermal distribution across the cabinet. Adicionalmente, o split power supply architecture separates high and low voltage areas, minimizing heat concentration and boosting safety.

🔌 Maintenance and Installation Flexibility

Designed with modular front and rear access, the FP Series allows for quick maintenance, ensuring minimal downtime. O 960×960mm standard cabinet size simplifies multi-screen installations, and its scalable design supports a wide range of display shapes and configurations.

🚀 Why Choose the LEDcheer FP Series?

• ✅ IP65-rated waterproof and dustproof protection
• ✅ High-brightness, high-refresh outdoor performance
• ✅ Wide range of pixel pitch options (P4.44–P10)
• ✅ Dual-voltage design for international use
• ✅ Lightweight yet durable 960mm cabinet
• ✅ 100,000 hours operational lifespan

Whether you're building a roadside billboard or an open-air concert screen, the LEDcheer FP Series is your reliable and high-impact solution.
